How to Use Distributed SQLite and Merkle Trees to Detect Divergence

In Part 1, we explored how a Merkle tree inside SQLite can turn a local database into a tamper-evident ledger. That gave us local immutability: a single .db file could prove its history hadn’t been altered.

Now we’ll take the next step: imagine each database file is a peer in a network. Each peer appends events to its own ledger and computes a Merkle root as a cryptographic fingerprint. By exchanging and comparing roots, peers can quickly detect whether their histories diverge.

This pattern — multiple independent ledgers, compared by fingerprints — underlies real systems like Git, blockchains, and distributed databases.

---

Why “Distributed SQLite”?

SQLite itself is not distributed. But by treating multiple .db files as independent peers, we can:

• Simulate distributed immutability without infrastructure overhead.
• Teach how Merkle roots summarize history compactly.
• Show how peers can detect divergence with minimal data exchange.

This demo isn’t production-ready, but it’s the perfect teaching tool.

All the code is available on GitHub.

---

Step 1: Append-Only Ledgers in SQLite

Each peer maintains its own ledger table. In our repo, this is managed by ledger.py:

import sqlite3, time, hashlib

def init_db(db_file: str) -> sqlite3.Connection:
    conn = sqlite3.connect(db_file)
    conn.execute("""
        CREATE TABLE IF NOT EXISTS ledger (
            id INTEGER PRIMARY KEY AUTOINCREMENT,
            timestamp REAL NOT NULL,
            data TEXT NOT NULL,
            hash TEXT NOT NULL
        )
    """)
    conn.commit()
    return conn

def add_record(conn: sqlite3.Connection, data: str) -> int:
    timestamp = time.time()
    record_hash = hashlib.sha256(data.encode('utf-8')).hexdigest()
    cursor = conn.execute(
        "INSERT INTO ledger (timestamp, data, hash) VALUES (?, ?, ?)",
        (timestamp, data, record_hash)
    )
    conn.commit()
    return cursor.lastrowid

Records are append-only: each entry gets a timestamp, data, and SHA256 hash.

---

Step 2: Compute Merkle Roots

The merkle.py module builds a Merkle tree from ledger rows:

def sha256(data: str) -> str:
    return hashlib.sha256(data.encode("utf-8")).hexdigest()

def compute_merkle_root(hashes: list[str]) -> str:
    if not hashes: return sha256("")
    if len(hashes) == 1: return hashes[0]
    next_level = []
    for i in range(0, len(hashes), 2):
        left = hashes[i]
        right = hashes[i+1] if i+1 < len(hashes) else left
        next_level.append(sha256(left + right))
    return compute_merkle_root(next_level)

def merkle_root(conn) -> str:
    cursor = conn.execute("SELECT id, data FROM ledger ORDER BY id")
    records = cursor.fetchall()
    if not records: return sha256("")
    record_hashes = [sha256(f"{id_val}:{data}") for id_val, data in records]
    return compute_merkle_root(record_hashes)

This gives each peer a single hash that represents its entire ledger. Any change — even one byte in one row — produces a completely different root.

---

Step 3: Object-Oriented Peers

To make things easier to work with, the repo includes a Node class in node.py:

from ledger import init_db, add_record
from merkle import merkle_root

class Node:
    def __init__(self, name, db_file):
        self.name = name
        self.db_file = db_file
        self.conn = None

    def initialize(self):
        self.conn = init_db(self.db_file)
        return self

    def add_event(self, data: str):
        return add_record(self.conn, data)

    def get_merkle_root(self) -> str:
        return merkle_root(self.conn)

    def compare(self, other):
        root_self = self.get_merkle_root()
        root_other = other.get_merkle_root()
        return root_self == root_other

This abstraction makes it easy to spin up multiple nodes and compare them.

---

Step 4: Compare Peers

Let’s see it in action. Create two nodes with the same events:

from node import Node

nodeA = Node("Alice", "alice.db").initialize()
nodeB = Node("Bob", "bob.db").initialize()

for event in ["Alice pays Bob 10", "Bob pays Carol 5"]:
    nodeA.add_event(event)
    nodeB.add_event(event)

print("Node A root:", nodeA.get_merkle_root())
print("Node B root:", nodeB.get_merkle_root())
print("Identical?", nodeA.compare(nodeB))

✅ Both roots match — the ledgers are consistent.

Now diverge:

nodeB.add_event("Carol pays Dave 3")
print("Identical?", nodeA.compare(nodeB))

⚠️ Roots differ — the nodes know they’re out of sync.

---

Step 5: Network-Wide Analysis

The repo also includes a compare_network function to check many nodes at once:

from node import compare_network

network = [nodeA, nodeB, Node("Charlie", "charlie.db").initialize()]
analysis = compare_network(network)

print("Sync groups:", analysis["sync_groups"])
print("Network healthy?", analysis["network_healthy"])

This shows which nodes are in sync and whether the network is “healthy” (e.g. 80%+ agree).

---

Why This Matters

This demo is a simplified version of how real distributed systems work:

• Git: Each commit is a Merkle root. Repos diverge when their roots differ.
• Blockchains: Each block contains a Merkle root of transactions. Nodes gossip these roots to detect forks.
• Distributed databases: Systems like Cassandra use Merkle trees to detect replica drift.

The principle is the same everywhere: compact cryptographic fingerprints let peers compare histories without exchanging everything.

---

What’s Next

Now that each peer can detect divergence, the next step is:

👉 How do peers actually share and spread their roots across a network?

That’s the role of gossip protocols, which we’ll cover in Part 3.

---

Conclusion

By moving from a single SQLite ledger to multiple peers, we’ve shown how distributed immutability works:

• Each peer has its own append-only ledger.
• Each computes a Merkle root as a fingerprint of history.
• Peers can compare roots to instantly detect divergence.

This simple pattern is the foundation of Git, blockchains, and distributed databases — and now you’ve built it yourself with just SQLite and Python.
